icon 2021 2022 2023 GMC Canyon Single 30in Light Bar
$459.99
  • Product Description
  • Light Bar Specs
  • Shipping & Warranty
  • Fits 2023 2024 2025 Ford Super Duty F250 F350 F450
  • Trims:
    • F250XL, F350XL, F450XL
    • F250XLT, F350XLT, F450XLT
    • F250 Lariat, F350 Lariat, F450 Lariat
    • F250 King Ranch, F350 King Ranch, F450 King Ranch
    • F250 Platinum, F350 Platinum, F450 Platinum
    • F250 Limited, F350 Limited, F450 Limited



    • Curved LED light bar PRO
    • Perfectly follows the Ford Super Duty bumper and grille factory curvature
    • Stays slim to the bumper for a sleek, built in look
    • Must remove grille
    • No cutting or drilling required. The kit is a complete bolt on using factory openings and hardware.
    • Doesn't interfere with radiator air flow

    Dual Color:

    Main White LED Light with Amber DRL (daytime running lights)

    • White LED -- Super bright and crisp white beam pattern. It will definitely provide you with enough light needed for all of your adventures. However, these are only for off-roading and can’t be used on the regular road. They will blind the in-coming traffic and also violates road safety.
    • Amber DRL -- amber DRL “daytime running lights” acts purely for aesthetics. Since it doesn’t give out much light, you can use this amber DRL feature on regular roads, it doesn't blind in-coming traffic.





    Introducing our new LED light bar-PRO with a unique appearance and optimal performance.

    • Combo Pattern: combined spot and driving optics offers a balance between the distance and width
    • Uses TIR (Total Internal Reflection) lens is different from our the regular slim light bar. The TIR lens collects all of the light from the LED and directly leads them to where you need, drastically reducing glare and improving total efficiency.
    • Higher light efficiency: brighter, longer irradiation distance
    • Housing is upgraded to 304 aluminum. The surface is UV polyester powder coated to prevent against UV, salt water, corrosion, fading and scratch resistant.
    • Equipped with thermal management system that automatically adjusts the brightness output according to the external temperatures



    👍Our light kits are for off-road use only.


    WHAT'S INCLUDED?

    (1) 30in light bar Curved PRO

    (2) mounting brackets

    All mounting hardware

    WIRING

    • M&R Automotive doesn’t provide a wiring harness.
    • The light bar has 6ft of wire which is enough to reach AUX switches if your truck has them. Otherwise, you will need to purchase a generic wiring harness from Amazon/Ebay or create your own.

    • For this install, we used M&R wireless wiring harness. This makes it an easy, clean install without running wires inside the cab.


    INSTALLATION INSTRUCTIONS


    30in Light Bar Specs

    • Theoretical max power                160watts
    • Actual power                                  90watts
    • Main White light is                        7.5amps at 12v
    • Backlight Amber is                         0.19amps at 12v
    • Theoretical max luminous flux                   17,472 lm
    • Measured luminous flux (without lens)    11,072 lm
    • Measured luminous flux (with lens)           8,806 lm
    • LEDs type:                  luminus SST-20 Ra70
    • Temperature:            6000k
    • LEDs number:            16pcs

    All domestic (USA) orders are free shipping via USPS or UPS, depending on product size.
    We typically ship in 3-7 business days. If we are anticipating a delay with your shipment due to availability of the product, we will reach out to you via email.

    Canada, international or express shipping costs are calculated at checkout.

    You will receive an email with tracking number when your order is shipped.

    If you have a special request about your order, reach out, we try to accommodate as much as we can.

    For a complete shipping policy click here.


    We have a lifetime warranty on our light kits. We truly want our truck enthusiastic customers to enjoy their products as much as we enjoy designing them. However, we also understand that different situations arise with brackets or lights. For more information about our warranty and disclaimer click here.




    *M&R Automotive is not responsible for misuse or improper installation of the product. Professional installation is recommended.



    Customer Reviews

    Based on 17 reviews
    94%
    (16)
    6%
    (1)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    A
    A.
    30” light bar pro

    Great looking light bar I have it mounted was very simple with factory switches

    A
    A.S.
    30 inch light bar

    The light bar is awesome. Nice and bright. i also bought a harness to attach to my current harness so no spicing was needed. Works great

    K
    K.H.
    Great light bar

    Awesome product, great performance.

    R
    R.H.
    2025 F250 30” Light Bar Pro

    Excellent fit. Mounting was straightforward and easy. Would definitely recommend.

    J
    J.
    Great Product, Extraordinary Customer Service!

    I installed the 30 inch light bar on my Ford F-250 XLT over the weekend. We use this vehicle for towing, not off road use, and specifically purchased this product because it is relatively unobtrusive on the grill, and offers amber marker lights. The product itself has a very high-quality feel, all metal, no plastic anywhere. The fitment tolerances are very tight and sturdy. I didn't want to change the look of the truck too much, which is why we went with M&R instead of another brand. This light bar blends very nicely with the overall look of the vehicle, and fits perfectly in the groove in the front bumper.

    During installation I had a small amount if trouble getting everything to line up. I sent an email to M&R, wondering if I had the wrong brackets. Mike from M&R called me about 15 mins later, and I was able to resolve the issue. Basically, user error on my part - One of the plastic clips for the engine block heater wiring harness had gotten pinched between the M&R bracket and the frame, which threw everything out of alignment. After figuring this out, the rest of installation was very easy. The included wiring harness is just long enough to connect to the auxiliary switches on the truck.

    The white lights are extremely bright and definitely not road legal, but will be useful for the occasional times we are pulling into or out of a dark campground at night. The amber marker lights appear about as bright as any of the other amber lights on the truck, and will work very well for towing.
