The Ford F-150 Tremor is the one you buy when you want the off-road hardware from the factory — the wider track, the skid plates, the modular front bumper, the go-anywhere attitude — without stepping all the way up to a Raptor. Ford built it to leave the pavement. But look at the front of that truck after dark and you'll notice the one thing they left basic: the lighting.
That's exactly the gap these two new kits close — and both are engineered specifically for the 2024+ Tremor's modular bumper, not adapted from something universal. A fog light kit with a shroud molded to fit the Tremor's bumper, and a curved 40-inch bar that follows the factory lines. Here's the full rundown, plus how each one installs.
A quick word on the F-150 Tremor
The Tremor package turns the F-150 into a genuine factory off-roader: a one-inch front lift and retuned suspension, a wider stance, available 33-inch tires, an electronic locking rear diff, Trail Control, skid plates, and — the important part here — a unique modular front bumper designed to take accessories. It's a truck that's meant to be built on. The bumper's fog light pockets are the perfect place to start, and the curved lower opening is tailor-made for a bar.
The fog light kit — the upgrade the Tremor's been waiting for
Start here, because this is the one. For as capable as the Tremor is, its factory fog lights are an afterthought — and until now, there hasn't been a fog kit actually shaped for its modular bumper. Owners were left zip-tying universal pods into an opening they were never designed for, with gaps, brackets that don't line up, and a look that screams aftermarket. This kit was engineered from the ground up for that exact bumper. It drops into the factory fog pockets, reuses the factory bolts and clips, and finishes the front end like Ford should have.
It's a complete, bolt-on replacement for both factory fog lights — sold as a pair — and every piece of it is built to a higher standard than the housing it replaces.
The 3D-printed shroud — the part that makes it fit
Each side gets a custom 3D-printed shroud printed in ASA-GF (glass-reinforced ASA) — the same class of material used for demanding automotive parts, not the brittle plastic you'll find on cheap pods. That matters:
- Molded for the Tremor's modular bumper — an OEM-style finish designed for a clean, seamless, integrated look. It sits flush, not bolted-on.
- UV- and weather-proof — won't fade, crack, or break down in sun, rain, heat, or cold.
- Fiber-reinforced strength — rigid and durable, built to take the abuse of real off-road use.
Two pods per side — fog spread and driving distance
This isn't a single-pod fog light. Each shroud houses two PRO pods — four pods total across the kit — so you get both close, wide coverage and long-distance throw at the same time:
- 20-watt pod — fog beam. Angled 15° outward for a wide spread that fills in the sides and the near foreground — exactly where a fog light should work.
- 40-watt pod — driving beam. Aimed straight ahead for distance and throw down the trail or road.
Dual color, PRO build
Both pods are dual-function PRO pods, so you pick your main-beam color and always get a street-safe amber DRL:
- White + Amber DRL — the brightest, crispest all-around beam.
- Yellow + Amber DRL — cuts through dust, fog, snow, and rain far better than white; the pick if you run bad weather.
The white and yellow main beams are for off-road use only. The amber DRL gives off little light, won't blind oncoming traffic, and is street-safe — run it day or night. Under the shrouds, these are full PRO-grade optics: a TIR (Total Internal Reflection) lens that collects the LED output and directs it where you need it with minimal glare, a 304-aluminum housing with UV powder coat, a thermal management system that adjusts output with temperature, and a 50,000-hour rated lifespan.
What's in the kit
- A pair of 3D-printed ASA-GF shrouds, molded for the 2024+ F-150 Tremor modular bumper
- Four PRO pods total — two per side (one 20w fog, one 40w driving)
- Your choice of White + Amber DRL or Yellow + Amber DRL
- Mounting hardware that reuses the factory bolts and clips — no drilling
How to install the Tremor fog light kit — step by step
This is a true bolt-on: no cutting, no drilling, and fully reversible. Plan on roughly one to two hours with basic hand tools (a socket set and a trim/panel tool are all you need). Reference the full video below as you go.
- Prep the truck. Park on level ground, engine off, parking brake set. Before touching any wiring, disconnect the negative battery terminal.
- Remove the factory fog lights. Locate the stock fog housings in the modular bumper. Release the factory clips and bolts, unplug the OEM connector, and set the factory units aside — nothing here is permanent, so keep them if you ever want to revert.
- Identify driver vs. passenger. The shrouds are side-specific. Dry-fit each one first and confirm the 20w fog pod sits outboard (angled outward) and the 40w driving pod sits inboard/straight before you bolt anything down.
- Seat and secure the shrouds. Drop each 3D-printed shroud into the factory fog opening. Because it's molded for the Tremor bumper, it lines up with the same mounting points — reuse the factory bolts and clips to lock it in. No drilling.
- Route the wiring. Run each pod's leads back toward your control source, keeping the harness clear of moving parts, the exhaust, and any pinch points. Secure it along the way.
- Connect to power. Two clean options: tap your factory AUX / upfitter switches if your Tremor has them, or run everything to the M&R Wireless 8-Switch Harness — no firewall pass-through, no splicing factory wiring. Wire the white/yellow main beams to a switch; the amber DRL can run to an ignition/constant source so it acts as a running light.
- Reconnect the battery and test. Power up and test the main beam and the amber DRL separately. Confirm both sides light and match.
- Aim, tighten, and tidy. Fine-tune the aim to taste (40w for distance, 20w for spread), snug down all fasteners, secure any loose wiring, and you're done.
Prefer to watch it done? Here's the full fog kit install, start to finish:
The 40-inch light bar — distance down the trail
Where the fog kit fills the foreground, the bar reaches way out. The Tremor 40in Light Bar PRO is a curved bar that follows the bumper and grille curvature for a slim, built-in look — and the best part of the install: you don't have to remove the grille or bumper. It's a complete bolt-on using factory openings.
It runs a PRO Combo beam (spot + driving) for a blend of distance and width, with the same dual-color choice — White + Amber DRL or Yellow + Amber DRL — plus the TIR lens, 304-aluminum housing, and thermal management of the rest of the PRO line.
How to install the Tremor 40in light bar
One of the easiest bar installs we make — no grille or bumper removal.
- Bench-test first. Connect the bar briefly before mounting to confirm it lights and you like the color.
- Position it on the bumper. The curved bar installs righ ton top of the bumper, following the factory line.
- Bolt to the factory points. Mount the powder-coated brackets using the Tremor's factory openings and hardware — no cutting, no drilling.
- Route the wiring. Run the lead back to your AUX switch or wireless harness. The bar has over 6ft of wire to reach the factory AUX wiring.
- Level, tighten, and test. Set the bar straight, tighten it down, and test the main beam and amber DRL.
Prefer to watch it done? Here's the full bolt-on install, start to finish:
Powering it all — the easy way
Between the fog kit and the bar, you've got several circuits to run. Two clean options: if your Tremor has factory AUX switches, the kits plug right in. If not — or if you want the simplest install — the Wireless 8-Switch Harness runs up to 8 accessories from one rechargeable, magnetic wireless remote in the cab, with no firewall pass-through and no splicing into factory wiring.
Run them together
Individually, each kit is a serious upgrade. Together, they finish the Tremor's front end the way the factory should have: the fog kit lays down a wide, near wall of light for dust, weather, and the edges of the trail, while the 40in bar throws the distance. Both bolt on, both keep the factory look, and both are built specifically for your bumper.
FAQ: F-150 Tremor Fog Lights & Light Bar
Will these fit my F-150?
They're built specifically for the 2024–2026 Ford F-150 Tremor with the modular bumper. They're engineered around that bumper, so they won't fit other F-150 trims.
Do I have to cut or drill anything?
No. Both kits are complete bolt-ons that reuse factory openings and hardware. The fog kit reuses your factory fog-light bolts and clips; the bar mounts without removing the grille or bumper.
When does the fog kit ship?
The Tremor fog light kit is available to order now and ships starting September 1. The 40-inch bar ships now.
What's in the fog kit?
A pair of 3D-printed shrouds (glass-reinforced ASA), each running a 20-watt fog pod and a 40-watt driving pod — four PRO pods total — with your choice of White + Amber DRL or Yellow + Amber DRL.
Can I change the beam pattern?
Yes. The standard setup is a 20w fog beam and a 40w driving beam per side. If you want a custom pattern, email us before ordering and we'll set the lenses up your way.
Are they street-legal?
The amber DRL accents are street-safe and can be run on the road. The high-output white and yellow main beams are for off-road use only.
How do I control everything?
Through factory AUX switches if equipped, or the M&R Wireless 8-Switch Harness — up to 8 circuits from a wireless in-cab remote, no firewall drilling.
Shop the Build
Everything for the 2024+ F-150 Tremor's front end, bolt-on with no drilling:
- Tremor Fog Light Kit — 3D-printed shrouds, dual PRO pods per side (ships Sept 1)
- Tremor 40in Light Bar PRO — curved, built-in look, no grille removal
- Wireless 8-Switch Harness — control it all from the cab
