2024+ Ford F150 Ditch Lights
What's in the Box
- (2) 40w LED PODs standard
- (2) metal brackets
- (1) wiring harness to bridge 2 pods together
- All mounting hardware included
- *Brackets-only orders include just the mounting brackets — no pods or wiring harness.
Off-road use only
Bolt On, No Drilling
Vehicle Specific Design
Lifetime Warranty
Fits: 2024–2026 Ford F150
- Low profile
- Fully adjustable pods — aim them straight ahead for extra light down the trail, or angle them outward for a wider coverage area to light up the sides and spot obstacles, animals, or drop-offs in the ditches
- Easy bolt-on install — no cutting or drilling required
- Hood opens and closes freely
- Doesn't interfere with windshield wipers
- Metal bracket is powder coated
DUAL COLOR
The standard light POD uses a Spot pattern — a narrow, concentrated beam built for maximum throw distance down the trail, rather than the wider side coverage of a driving or flood beam.
Every standard POD is dual function — a white main light and amber DRL (daytime running light) backglow.
- White LED — Bright main beam for trail visibility. Off-road use only — the white beam blinds oncoming traffic and isn't street-legal.
- Amber DRL — A daytime running light you can run day or night. Doesn't give off much light — just a bold amber backglow that makes your vehicle stand out on the road. Street-legal — won't blind oncoming traffic, so you can run it anywhere.
BUILD QUALITY:
- Reflector-style optics with CREE XT-E LED chips for consistent, efficient output
- Housing is UV black powder coated to protect against fading, corrosion, and weather exposure
- Rated for a 50,000 hour lifespan
⚠️ Brackets-Only Orders: M&R does not guarantee fitment with other brand LED pods. Brackets are designed for 3.2in pods. All bracket-only sales are final — no returns.
40W Standard LED Light Pod
| Beam Pattern | Spot |
| Theoretical Max Power | 40 watts |
| Actual Power | 38 watts |
| Voltage / Current (Main) | DC 12V / 3.15A |
| Voltage / Current (Backlight) | DC 12V / 0.09A |
| Theoretical Max Luminous Flux | 5,032 lm |
| Measured Flux (without lens) | 3,840 lm |
| Measured Flux (with lens) | 1,944 lm |
| LED Type | Cree XM-L2 |
| Color Temperature | 6000K |
| Number of LEDs | 4 pcs |
| Product Size (L × W × D) | 3.19 × 2.88 × 2.72 in |
40W PRO vs Standard — Beam & Output
How far & how wide each 40W pod throws light
| Beam Pattern | Driving | Spot |
| LED Type | Luminus SST-20 | Cree XM-L2 |
| Color Temperature | 6000K | 6000K |
| Number of LEDs | 4 pcs | 4 pcs |
| Theoretical Max Power | 40 watts | 40 watts |
| Actual Power | 39.2 watts | 38 watts |
| Theoretical Max Luminous Flux | 4,368 lm | 5,032 lm |
| Measured Flux (without lens) | 3,940 lm | 3,840 lm |
| Measured Flux (with lens) | 2,949 lm | 1,944 lm |
| Light that makes it out | 75% | 51% |
| Product Size (L × W × D) | 3.25 × 3.15 × 2.78 in | 3.19 × 2.88 × 2.72 in |
| Best for | Bright, wide coverage | Tight focused spot |
Free ground shipping on all orders within the continental United States.
We process and ship orders within 3–5 business days. If we anticipate any delay, we'll reach out via email.
- Hawaii, Alaska & Puerto Rico — $20 flat rate for ground shipping.
- Canada & International — Shipping rates calculated at checkout. Customs fees, duties, and import taxes are the responsibility of the customer.
- Overnight & 2nd Day Air — Available at checkout. Orders must be placed by 12:00 PM Pacific Time for same-day shipment.
You'll receive a tracking number via email once your order ships. If you have a special request about your order, reach out — we'll do our best to accommodate. For our complete shipping policy, [click here].
Warranty
We have a lifetime warranty on all our light kits. We stand behind every kit we build — our lifetime warranty isn't fine print, it's a promise. For more information about our warranty and disclaimer, [click here].
M&R Automotive is not responsible for misuse or improper installation of the product. Professional installation is recommended.
HOW TO INSTALL?
Install Video
Light Output
